The TZ-70-70 automatic silage wrapping machine with double-film wrapping technology (single bale size 70×70cm) combined with automatic opening and wrapping process, up to 80 bundles/hour high output.

Compared with the traditional manual operation, the efficiency of the machine is increased by 5 times, and the sealing is 99% anaerobic environment. It ensures the stable fermentation of lactic acid bacteria, the crude protein retention rate of feed exceeds 95%, and the feed is stored in the open air for 2-3 years without spoilage.

The electric drive design with an intelligent overload protection system reduces the failure rate by 40%, providing an all-weather, continuous operation guarantee for large-scale farms and feed processing enterprises.

working video of silage hay baling wrapping machine

With 750kg/m³ high-density baling and double-film laminated wrapping technology, TZ-70-70 realizes precise control of the weight of single bale (60-100kg adjustable), and the transportation loss rate is less than 0.5%.

The equipment adopts modularized design, supporting one-key switching of the number of wrapping layers (2-6 layers), adapting to the needs of different storage cycles.

Compared with the traditional silage tank, the comprehensive cost per ton of feed is saved by 30%, which helps the average annual income of the ranch to increase by more than 25%.

 hay baler machine
hay baler machine
finished production from hay baler
finished production from a hay baler

Features of TZ-70-70 silage wrapping machine

  • With double film winding, you get a quicker wrapping speed and improved efficiency.
  • The finished bale is impressively large, capable of holding a significant amount of silage at once.
  • It is versatile and can manage all types of silage, making them suitable for a variety of applications.
  • The silage wrapping machine is super easy to operate, and one person can handle it all on their own. It’s a real time-saver!
automatic hay baler wrapper machine
automatic hay baler wrapper machine

Structure of corn silage baler and wrapper

The corn silage baler and wrapper mainly includes the bottom frame, belt conveyor, ball bin, rotating frame, film transferring mechanism, film pressing, and cutting mechanism, baling motor and rotating motor, etc.

forage baler wrapper machine
forage baler wrapper machine

How does the silage baler wrapper work?

The workflow of the silage wrapping machine is divided into two steps:

  • Baling stage: the kneaded straw or forage grass is fed into the baling bin and extruded by the pressure roller to form cylindrical bales (usually 70cm in diameter, weighing about 80kg per bale), which will be triggered by automatic rope wrapping when the density of the forage reaches the set value.
  • Film wrapping stage: the bales automatically fall into the rotating frame after baling, and through setting the number of film wrapping layers, wrapping the special pasture film layer by layer to form a sealed anaerobic environment.
silage feed baling machine working video

Parameters of forage baler wrapper machine

ModelTZ-70-70
Power11kw+0.55kw+0.75kw+3kw+0.37kw electric motor
Bale sizeΦ70*70cm
Bale weight150-200kg/bale
Capacity55-75bales/h
Air compressor volume0.36m³
Feeding conveyor(W*L)700*2100mm
Filming cuttingAutomatic
Wrapping efficiency6layers need 22s
Size4500*1900*2000mm
Weight1100kg
forage silage wrapping machine’s parameter

Difference between TZ-70-70 and TS-55-52 silage round baler

  • The power options for the 70 types of silage wrapping machines are exclusively electric motors, while the 50 types can run on either electric motors or diesel engines.
  • When it comes to size, the 70 types of silage wrapping machines measure 70 x 70, whereas the 50 types are slightly different at 50 x 52.
  • For binding grass, the 70-type baling and wrapping machines rely solely on net rope, but the 50 types have the flexibility to use both net rope and grass rope.
  • The 70-type silage wrapping machine operates fully automatically, while the 50-type machine offers a choice between automatic and semi-automatic functions.
silage baler and wrapper machine
silage baler and wrapper machine

Machines that can work with automatic silage feed balers

The TZ-70-70 silage wrapping machines are designed to handle a larger volume of materials all at once. They can work in conjunction with a chaff cutter and a feed mixer. (Read more: Silage Chaff Cutter Animal Feed Grass Cutting Machine>>)

First, you can process the forage into a fluffy consistency, and then transfer it into the feed mixer. Once mixed, the forage can be sent directly onto the conveyor belt of the baler.

automatic silage feed balers
automatic silage feed balers

CE certificate of silage baler machine

We’ve got the CE certificate for the silage baler wrapper machine. If you need it, just let us know, and we’ll share all the details about the certificate with you.

silage baler machine certificate
silage baler machine certificate

FAQ

Can I buy the net rope and film separately?

Yes.

Can I adjust the number of layers of wrapping film by myself?

Yes, you can adjust the number of layers according to your needs.

What kind of forage is easier to handle?

We recommend you use a kneading machine to process flocculent forage because it is easier to roll the forage together and not easy to spread out.

Do you have a CE certificate?

Yes, we do.

What is the power of the machine?

The power of TZ-70-70 machines can only be an electric motor, 50 types can be an electric motor and diesel engine.
