複合草粒破砕機チャフカッターグラインダーマシン

The combined grass grain crusher is a multifunctional feed handling equipment. We can use the machine to cut the grass but also to crush a variety of grains, fruits, and vegetables. The processed material is generally used to feed cattle, sheep, horses, pigs, and other livestock.

The machine is compact and portable but can produce up to 1800kg/h. It can also work with a silage baling machine to make the livestock feed.

Introduction to the combined grass grain crusher

Our factory produces many different models of combined grass grain crushers. The most popular ones are the five-port chaff cutter grinder machine and the four-port. There are two models of the four-mouth chaff cutter and grinder that are more popular. They are 9ZF-500B and 9ZF-1800 respectively. They handle the same materials.

Regarding power, they can be electric motors, gasoline engines, and diesel engines. The specific power depends on the specific machine model and the customer’s needs. They can not only cut, crush, and knead the straw, forage, etc. The following is a detailed description of the machine. Need more information about the machine welcome to contact us!

The range of chaff cutter grinder machines use

The chaff cutter grinder machine can handle straw types, such as corn stalks, bean stalks, straws, rice straws, wheat straws, pasture grass, peanut seedlings, groundnut seedlings, etc. Also can handle fruits, vegetables, etc.

How does the chaff cutter grinder machine work?

Type 1: Four-port combined grass grain crusher

The four-port combined grass grain crusher has two outlets and two inlets. One outlet discharges the crushed grass and one outlet discharges the crushed grain. Therefore the two materials also enter through different inlets.

The machine has blades and hammer blades inside. Therefore, the straw or stalk can be processed into segmented and shredded products. In addition, there is a screen inside the machine. Customers can change the screen with different mesh sizes according to their needs.

Structure of the silage feed cutting grinder

The structure of both models of silage feed cutting grinder is similar, mainly including a cutting inlet, miscellaneous grain inlet, high spray outlet, pulverizing outlet, cut shredding system, power (motor, gasoline engine, diesel engine), mobile casters (can be customized pneumatic tires), frame, etc.

Poultry feed grinder parameters

The parameters of the 9ZF-500B poultry feed grinder. The output of the machine is smaller and can reach 300-500kg per hour.

モデル	500B
Motor speed	2800 rpm
容量	300KG-500KG/H
Crushing power	3kw
重さ	55KG（not including power）
Chaff cutting capacity	1200KG
Matching screen	4 (2/3/10/30)

The output of the 9ZF-1800 combined grass grain crusher can reach 1800kg per hour.

Machine model	9ZF-1800
Motor speed	2800 rpm
Rated voltage	220V
力	3KW
機械重量	75KG
Machine output	1800KG/H
Scope of application	Cows, sheep, pigs, chickens, ducks, rabbits, and other livestock

What are the advantages of straw cutter and grain grinder?

• The straw cutter and grain grinder are widely used. They can handle a variety of materials, such as straw, forage, vegetables, fruits, grains, etc. It can meet people’s needs for diverse and nutritious feed.
• The machine has a variety of functions in addition to the guillotine but also can crush a variety of grains, and fruits. In addition to this, the forage can also be kneaded into shreds.
• The machine has casters for easy movement, saving time and energy to move the machine.
• Various models of the machine can meet the different requirements of users for production. At the same time, different powers can meet the needs of different regions.

Type 2: Five-port combined grass grain crusher

The five-port combined grass grain crusher is based on the four-port with one more outlet. Of the three discharge ports, the one coming out from the top is dry material, the one coming out from the middle is more watery material, and the one coming out from the bottom is grain.

So the machine can automatically distinguish different materials. The other parts are similar to type 1. The machine is also equipped with 5 screens. And customers can choose the right mesh size according to their needs.

What is the structure of the silage feed cutting grinder?

The structure of the silage feed cutting grinder is similar to that of type 1. It mainly consists of a frame, wheels, grain inlet, guillotine inlet, power, high spray outlet, medium spray outlet, low spray outlet, etc. The overall structure of the combined grass grain crusher is compact and fully functional.

Detailed technical parameters of the chop cutter machine

モデル	9ZF-500
Motor speed	2800 rpm
力	3KW
機械重量	68KG
Machine output	1200KG
サイズ	1220*1070*1190mm
Matching screen	4 (2/3/10/30)

What are the good points of the cow feed cutting machine?

• The kneading function of the combined grass grain crusher can make corn stalks, bean stalks, straws, and other crops and wild weeds into softer filaments. This shredded material is easy for cattle, sheep, and further digestion and absorption.
• The machine has advanced design, smooth operation, easy operation, energy saving, safety and reliability, and many other advantages.
• At the same time, combined grass grain crusher out of the material is also conducive to baling transport and storage. It is a necessary machine for the majority of cattle and sheep farmers and small and medium-sized feed processing plants in the breeding area.

Export chaff cutter and grinder to Sudan

Yesterday, a customer from Sudan bought a 9ZF-500 combined grass grain crusher from us. The customer has a breeding plant, mainly feeding cattle and sheep. Therefore, a large amount of forage has to be processed every day.

To improve the efficiency of forage processing, the customer needed a professional forage processing machine. So the customer searched for the machine on the internet and found our website. After browsing, the customer contacted us.

We immediately sent pictures and videos of the machine and related parameters to the customer. We also recommended a machine model that suited the customer’s needs. After consideration, the customer decided to buy a five-bite chaff cutter grinder.

Contact us at any time

Our company is specialized in manufacturing silage processing machines with rich experience. If you are also engaged in related business, we will be your best choice, welcome to browse this website and feel free to contact us, we look forward to cooperating with you!
